CMW Series Oil-Free Laser Compressor

As one of the laser compressor manufacturers, suppliers, and exporters of mechanical products, We offer laser compressor and many other products.

Please get in touch with us for details.

Mail:[email protected]

Manufacturer supplier exporter of laser compressor.

CMW Series Oil-Free Laser Compressor

A laser compressor is a device that increases the pressure of a gas (usually nitrogen) to a level suitable for use in a laser. The compressed gas is used to cool the laser tube, which helps extend its life and improve its performance.

There are two main types of laser compressors: reciprocating and screw.

Reciprocating compressors use pistons to compress gas, while screw compressors use rotating screws. Reciprocating compressors are usually less expensive than screw compressors, but they are also less efficient. Screw compressors are more expensive than reciprocating compressors, but they are also more efficient.

Laser compressor is an important part of many laser systems. They help to improve the performance and prolong the life of the laser tube. By learning about the different types of laser compressors and the factors to consider when choosing, you can choose the right compressor for your needs.

CMW Series Oil-Free Laser Compressor Parameters:

Model

Motor power

Working

pressure

FAD

Noise

Compressed Air

Outlet Diameter



Weight

Dimension

L×W×H

kW

HP

MPa

L/min

cfm

dB(A)

inch

kg

mm

CMW2.2-0.8

2.2

3

0.2-0.8

255

9

49±3

1/2″

132

670×630×945

CMW3.7-0.8

3.7

5

0.2-0.8

415

15

52±3

1/2″

150

720×680×1050

CMW4.4-0.8

2.2×2

6

0.2-0.8

510

18

52±3

1/2″

150

800×650×1020

CMW7.4-0.8

3.7×2

10

0.2-0.8

830

29

55±3

1″

185

880×720×1120

CMW11-0.8

3.7×3

15

0.2-0.8

1245

44

58±3

1″

300

1450×900×1150

CMW15-0.8

3.7×4

20

0.2-0.8

1660

59

61±3

1″

350

1450×900×1150

CMW2.2-1.0

2.2

3

0.2-1.0

215

7.6

49±3

1/2″

132

670×630×945

CMW4.5-1.2

4.5

6

0.2-1.0

410

14.5

52±3

1/2″

150

720×680×1050

CMW4.4-1.0

2.2×2

6

0.2-1.0

430

15

52±3

1/2″

150

800×650×1020

CMW9-1.0

4.5×2

12

0.2-1.0

820

29

58±3

1″

185

880×720×1120

CMW13.5-1.0

4.5×3

18

0.2-1.0

1230

43.3

61±3

1″

300

1450×900×1150

CMW18-1.0

4.5×4

25

0.2-1.0

1640

58

61±3

1″

350

1450×900×1150

CMW3.0-1.2

3

5

0.2-1.2

210

7.4

49±3

1/2″

135

670×630×945

CMW4.5-1.2

4.5

6

0.2-1.2

360

12.7

52±3

1/2″

150

720×680×1050

CMW6.0-1.2

3×2

8

0.2-1.2

420

14.8

52±3

1/2″

150

800×650×1020

CMW9-1.2

4.5×2

12

0.2-1.2

720

25.4

58±3

1″

185

880×720×1120

CMW13.5-1.2

4.5×3

18

0.2-1.2

1080

38

61±3

1″

300

1450×900×1150

CMW18-1.2

4.5×4

25

0.2-1.2

1440

50.8

61±3

1″

350

1450×900×1150

Notes: The company reserves the right to improve technology continuously; any data changes will be informed beforehand.

CMW Series Oil-Free Laser Compressor Feature:

The new model is 15%-20% more energy efficient than piston air compressors. After the piston ring and cylinder body wear, it saves 30%-40% more power than the piston air compressor. Two years of saving is equivalent to the cost of buying a machine.

Box design, no vibration, low noise, small volume.

Fewer consumables, low cost.

Environmental protection, oil-free design, ISO08573-1 oil-free certification.

Isothermal compression, low exhaust temperature, and low water content of compressed air.



We are one of the best food compressor suppliers. We have exported our products to clients around the world and earned a good reputation because of our superior product quality and after-sales service. We warmly welcome customers both at home and abroad to contact us to negotiate business, exchange information, and cooperate with us!

Laser Compressor Application
